DESCRIPTIONFOR FLEET MANAGEMENT AND BURGLAR
The MVT600 is the ideal fixed solution for vehicles since besides the vehicle tracking activity, it supports several regional functions related to the vehicle behavior, its safety etc. Using the U-blox 6 technology ensures maximum accuracy in monitoring and vehicle tracking while supports AGPS technology for alternative vehicle tracking via phone network in areas where it is not possible to collect data from satellites. The embedded acceleration and vibration sensors provide extra parameterization of the tracker’s operation in accordance to customer and applications needs, while there is the ability to directly interconnect the tracker to the vehicle immobilizer to get additional safety. Supports a set of optional external sensors such as gasoline, temperature, etc., as well as three digital inputs and three outputs and analog inputs to remotely control functions in the vehicle. The MVT600 is the most complete solution for vehicle applications, especially where the tracker size required is not limited.
Using a screwdriver Phillips type, remove the screw at the back of the unit, remove the cover with the indication SIM to access the SIM card slot.
Be sure that the SIM card has the relative pin unlock number deactivated. Insert the SIM card on the slot in the same direction as the indication, i.e. with the metal pins of the SIM at the bottom and the slot of the card to be inserted first into the tracker. Activate the tracker and as soon as you are assured that it is activated place the cover of the unit back. Make sure that it has been mounted correctly and screw the screw without applying excessive pressure.
Charge the device
Connect the 12 pin plug at the back side of the tracker and connect the tracker at a 12V or 24V source via the black (GND) and red (+SUPPLY) wires. For proper battery management, let the tracker charge for at least three hours.
The tracker is partially parameterized. What remains in order to assure the proper operation of the device is the end user to declare the selected mobile telecommunications service provider via which the tracker will communicate with the server (cosmote, Vodafone, wind etc.). With the tracker activated, we conclude the process described above by transmitting a message SMS, that contains the SIM card number, inserted in the tracker.
The content of the message exactly as it should be sent is shown below:
0000,A21,1,digitrack.gr,1000, the APN of the provider, username if that exists, password if that exists
This message applies to all mobile telecommunication networks, differentiated only at the APN parameter (blue fonts) the value of which depends on the provider selected by the end-user. The APN value could be immediately provided by the mobile telecommunication service provider stores network. If there exists a username and password to connect, these are entered in the message at the positions with the red and green fonts.
Otherwise the message will have the form as below:
(this is an example of a parameterization message with a mobile telecommunication service provider whose APN is “internet”, without username and password).
As soon as the process described above is concluded, the tracker is ready to operate. Be sure that all external antennas have been connected. What remains is to create a contact on the device the application DigiTrack is installed, taking into account that the IMEI of the tracker, which is affixed to its packaging, should be entered on the phone number of said contact.
Note: Buying the tracker is accompanied by free lifetime subscription of DigiTrack application. The end-user should declare the IMEI of the device the application DigiTrack is installed, when ordering the tracker at the UBILUS e-shop, to gain access to the mail server of the application.
